Mercusys MR50G User Manual

04
Chapter 2 Connecting the Router
5. Verify that the hardware connection is correct before continuing.
1. Turn o the modem, and
remove the backup battery if it
has one.
2. Connect an Ethernet cable from the
modem to the WAN port on your
router.
3. Power on the modem, wait about 2
minutes for it to restart.
Note: If your Internet connection is through an Ethernet cable from
the wall instead of through a DSL/Cable/Satellite modem, connect
the Ethernet cable directly to the router’s WAN port.
Internet
RouterModem
4. Power on the router.
Power Adapter
Power WAN 1 2
RESET
WPS

Mercusys MR50G Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1900 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Product type	Portable router
Product color	Black
Firewall security	IP and MAC Address Binding
Security algorithms	WPA-PSK, WPA2-PSK
Antennas quantity	6
Output current	1 A
Output voltage	12 V
Power source type	AC
Cables included	AC, LAN (RJ-45)
Package depth	267.5 mm
Package width	349.5 mm
Package height	80.5 mm
Package weight	760 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	157.2 mm
Width	175.6 mm
Height	45 mm
