05
Chapter 3  Quick Installation Guide
Chapter 3 Quick Installation Guide
This chapter will show you how to congure the basic functions of your router using
Quick Setup Wizard within minutes.
The Router provides two working modes: Wireless Router and Access Point. You
can choose the mode to better suit your network needs and follow the guide to
complete the conguration.
3.1 Set Up the Router in Wireless Router Mode
In this mode, the router can provide internet access for multiple wired and wireless
devices. This mode is required most commonly.
1. To access the web management page, open a web browser and enter the default
domain name http://mwlogin.net in the address eld.
2. A login window will appear. Create a login password when prompted. Then click
Let's Get Started. For subsequent login, use the password you have set.
3. Select your Time Zone and click NEXT.

Other manuals for Mercusys MR50G

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercusys MR50G and is the answer not in the manual?

Mercusys MR50G Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1900 Mbit/s
WLAN data transfer rate (first band)600 Mbit/s
WLAN data transfer rate (second band)1300 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Number of guest networks (2.4 GHz)1
Product typePortable router
Product colorBlack
Firewall securityIP and MAC Address Binding
Security algorithmsWPA-PSK, WPA2-PSK
Antennas quantity6
Output current1 A
Output voltage12 V
Power source typeAC
Cables includedAC, LAN (RJ-45)
Package depth267.5 mm
Package width349.5 mm
Package height80.5 mm
Package weight760 g
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth157.2 mm
Width175.6 mm
Height45 mm
