Mercusys MR50G User Manual

30
Chapter 5 Advanced Conguration
• Manual - In this mode, the internet connection is controlled manually by
clicking the Connect/Disconnect button. This mode also supports the Max
Idle Time function as On Demand mode. Enter a maximum time (in minutes),
the internet connection can be inactive before it is terminated into the Max
Idle Time. The default value is 15 minutes. If you want the internet connection
remains active all the time, enter 0 (zero).
Note:
Sometimes the connection cannot be terminated although you have specied the Max Idle Time because some applications
are visiting the internet continually in the background.
5. 1. 3. MAC Clone
1. Visit http://mwlogin.net, and log in with the password you set for the router.
2. Go to Advanced > Network > Internet and locate the MAC Clone section.
3. Congure Router MAC Address and click SAVE.
• Use Default MAC Address - Do not change the default MAC address of your
router in case the ISP does not bind the assigned IP address to the MAC
address.
• Clone Current Device MAC - Select to copy the current MAC address of the
computer that is connected to the router, in case the ISP binds the assigned
IP address to the MAC address.
• Use Custom MAC Address - Select if your ISP requires you to register the
MAC address and enter the correct MAC address in this eld, in case the ISP
binds the assigned IP address to the specic MAC address.
Note:
• You can only use the MAC Address Clone function for PCs on the LAN.
• If you have changed the WAN MAC address when the WAN connection is PPPoE, it will not take eect until the connection is
re-established.
5. 1. 4. LAN
1. Visit http://mwlogin.net, and log in with the password you set for the router.

Mercusys MR50G Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1900 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Product type	Portable router
Product color	Black
Firewall security	IP and MAC Address Binding
Security algorithms	WPA-PSK, WPA2-PSK
Antennas quantity	6
Output current	1 A
Output voltage	12 V
Power source type	AC
Cables included	AC, LAN (RJ-45)
Package depth	267.5 mm
Package width	349.5 mm
Package height	80.5 mm
Package weight	760 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	157.2 mm
Width	175.6 mm
Height	45 mm
