Mercusys MW330HP User Manual

MW330HP
300Mbps High Power Wireless N Router
5.1.5 MAC Address Settings
Go to Network→MAC Address Settings, you can configure the MAC address of the WAN on
the page.
Some ISPs require that you register the MAC address of your adapter. Changes are rarely
needed here.
• Use the router's MAC address - By default, this option is selected.
• Use the current computer's MAC address (MAC Clone) - Some ISPs will register the
MAC address of your computer when you access the Internet for the first time through
their Cable modem. If you add a router into your network to share your Internet connection,
the ISP will not accept it as the MAC address is changed. In this case, you need to clone
your computer’s MAC address to the router.
• Manually set MAC address - If your ISP requires you to register the MAC address, please
enter the correct MAC address into this field in XX-XX-XX-XX-XX-XX format (X is any
hexadecimal digit).
Click Save to make the settings effective.
NOTE:
Only the PC on your LAN can use the MAC Clone function.
- 25 -

Mercusys MW330HP Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	-90 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)	-78 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	-74 dBmW
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	9 V
Power source type	AC
Antenna gain level (max)	7 dBi
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK

Weight and Dimensions

Depth	127 mm
Width	192 mm
Height	36 mm
