Mercusys MW330HP User Manual

MW330HP
300Mbps High Power Wireless N Router
● Remote Management
To allow all devices to access and manage the router remotely, follow the steps below:
1. Select Allow all remote devices.
2. Enter the port number to be used to access the router between 1024 and 65535. The
default value is 8888.
3. Click Save.
To allow specified devices to access and manage the router remotely, follow the steps
below:
1. Select Allow specified remote devices.
2. Enter the IP Address you will use when accessing your router from the Internet.
3. Enter the port number to be used to access the router between 1024 and 65535. The
default value is 8888.
4. Click Save.
5.5.2 Time Settings
Go to System Tools→Time Settings, and then you can configure the time on the following
page.
NOTE:
1. To access the router, you should type your r
outer's WAN IP address into your browser's
address field, followed by a colon and the custom port number
(e.g.
http://202.96.12.8:8080).
After entering the correct password, you will be able to access
the router's web management page.
2. Be sure to set a very secure password for the router.
- 44 -

Mercusys MW330HP Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	-90 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)	-78 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	-74 dBmW
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	9 V
Power source type	AC
Antenna gain level (max)	7 dBi
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK

Weight and Dimensions

Depth	127 mm
Width	192 mm
Height	36 mm
