MW330HP
300Mbps High Power Wireless N Router
AP Isolation - Select this checkbox to enable the AP Isolation feature that allows you to
confine and restrict all wireless devices on your network from interacting with each other,
but still able to access the internet. AP isolation is disabled by default.
Enable SSID Broadcast - If you select the Enable SSID Broadcast checkbox, the wireless
router will broadcast its name (SSID) on the air.
5.2.2 Guest Network
Go to Wireless→Guest Network, then you can configure the settings for the wireless guest
network on this page.
Guest Network - Click to enable or disable the Guest Network function here.
SSID/Password - Set the network name and password for Guest Network. Password may
contain 8-63 characters. It is recommended you use a combination of numbers, letters
and symbols.
Access my local network - Select whether to allow wireless devices on the guest network
to access your local network. The default value is No.
Upstream Bandwidth - The upload speed through the WAN port for Guest Network.
Downstream Bandwidth - The download speed through the WAN port for Guest Network.
Set Guest Access Time - Set the time period to enable guest network.
5.2.3 WDS Bridging
Go to WirelessWDS Bridging, and follow the steps below to configure WDS bridging
settings.
- 30 -

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercusys MW330HP and is the answer not in the manual?

Mercusys MW330HP Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Product typeTabletop router
Product colorBlack
Wi-Fi bandSingle-band (2.4 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)-90 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)-78 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)-74 dBmW
Ethernet LAN (RJ-45) ports3
Output current0.6 A
Output voltage9 V
Power source typeAC
Antenna gain level (max)7 dBi
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Security algorithmsWPA-PSK, WPA2-PSK
Weight and Dimensions IconWeight and Dimensions
Depth127 mm
Width192 mm
Height36 mm
