MW330HP
300Mbps High Power Wireless N Router
Service Provider - The Dynamic DNS service provider.
Dynamic DNS Client Select to enable or disable dynamic DNS client.
Username/Password - Enter the username and password of your DDNS account.
Domain Name - Enter the domain name provided by the DDNS service provider.
To set up for Dynamic DNS, follow these steps:
1. Select your service provider from the drop-down list.
2. Enable the Dynamic DNS client.
3. Enter the username and password of your DDNS account.
If you do not have an account, click Go to registerto register an account.
4. Enter domain name you registered with the Dynamic DNS service provider.
5. Click Save.
5.5 System Tools
There are eight submenus under the Forwarding menu: Web Management, Time Settings,
Firmware Upgrade, Backup & Restore, Reboot, Change Login Password, Diagnostic Tools
- 42 -

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercusys MW330HP and is the answer not in the manual?

Mercusys MW330HP Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Product typeTabletop router
Product colorBlack
Wi-Fi bandSingle-band (2.4 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)-90 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)-78 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)-74 dBmW
Ethernet LAN (RJ-45) ports3
Output current0.6 A
Output voltage9 V
Power source typeAC
Antenna gain level (max)7 dBi
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Security algorithmsWPA-PSK, WPA2-PSK
Weight and Dimensions IconWeight and Dimensions
Depth127 mm
Width192 mm
Height36 mm
