Mercusys MW330HP User Manual

MW330HP
300Mbps High Power Wireless N Router
Appendix A: FAQ (Frequently Asked Questions)
Q1. What should I do if the login window does not appear?
• Make sure the router connects to the computer correctly.
• If the computer is set to a static IP address, change its settings to obtain an IP address
automatically.
• Verify that http://mwlogin.net is correctly entered in the web browser.
• Use another web browser and try again.
• Reboot your router and try again.
• Disable and enable the network adapter in use again.
Q2. What should I do if I cannot access the internet?
• Check if the internet is working properly by connecting a computer directly to the modem
via an Ethernet cable. If it is not, contact your internet service provider
• Reboot your router and try again.
• Open a web browser, enter http://mwlogin.net and run the Quick Setup again.
• For cable modem users, reboot the modem first. If the problem persists, log in to the web
management page of the router to clone MAC address.
Q3. How do I restore my router’s configuration to its factory default settings?
There are two ways to reset the router.
Method one: With the router powered on, press and hold the WPS/RESET button for at least 5
seconds,
then release the button and wait the router to reboot to its factory default settings.
Method two: Visit http://mwlogin.net
, go to Advanced → System Tools → Backup & Restore →
Factory Default Restore to restore the router to its default settings.
NOTE:
Once the modem router is reset, the current configuration settings will be lost and you will need
to re-configure the router.
- 51 -

Mercusys MW330HP Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	-90 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)	-78 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	-74 dBmW
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	9 V
Power source type	AC
Antenna gain level (max)	7 dBi
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK

Weight and Dimensions

Depth	127 mm
Width	192 mm
Height	36 mm
