Meyn 0100-5 - Torque Switch (if Applied)

Disassembly/assembly and adjustments
52 © Meyn Food Processing Technology B.V.
Figure 7.27 Remove a bottom unit
Bottom unit
• Remove four bolts (D).
• Remove unit.
7.2.11 Torque switch (if applied)
The torque switch is a machine protection.
If the machine hangs-up, this switch will stop the evisceration line.
Figure 7.28 Torque switch.
Adjust the Spring tension
If the machine is not turning stable it
might be necessary to change the spring
tension.
• Loosen nut (A).
• Turn bolt (B) to obtain the desired
spring tension.
• Tighten nut (A).
D
D
A
B
