Introduction
8 © Meyn Food Processing Technology B.V.
1.2 General arrangement drawing
Figure 1.2 Meyn Vent cutter outside and inside detail.
Meyn Vent cutter
The machine consists of the following main components:
Evisceration frame.
Main shaft.
Drive wheel (180° bend).
Hand wheel.
Drill unit.
Lift-up unit.
Capstan wheel.
Bottom cam.
Tail clip cam.
1. Top cam.
3
5
6
8
9
10
1
2
4
7
