Introduction
© Meyn Food Processing Technology B.V. 7
Table 1.5 Technical specifications.
Table 1.6 Technical specifications.
Specifications: 16x6”
Capacity max. ** 8,000 BPH Height (H) 2,150 mm
Live weight 0.5-3.8 kg Weight machine 650 kg
Number of units 16 Water connection 3/4”
Shackle pitch 6” Water consumption 0.6 m³/h
Length (L) 1,760 mm Drain connection DIN100
Width (W1) 1,345 mm Noise level 70 dB(A)
Width (W2) 780 mm
Specifications: 20x6”
Capacity max. ** 10,000 BPH Height (H) 2,150 mm
Live weight 0.5-3.8 kg Weight machine 850 kg
Number of units 20 Water connection 3/4”
Shackle pitch 6” Water consumption 0.6 m³/h
Length (L) 2,335 mm Drain connection DIN100
Width (W1) 1,640 mm Noise level 70 dB(A)
Width (W2) 970 mm
