1.5.3 Multiple Battery Module Backup Time at Full Load
Standard EX 5/7/11RT systems (one Power Module, and one Battery Module), offers a standard backup time of 5
to 12 minutes at full load.
To increase backup time, it is possible to connect up to 5 additional Battery Modules to the standard system. See
section 2.8 for connections between standard system and Battery Module (EXB 5/7/11RT)
Figure 1-9: Typical back-up time with multiple EXB’s at full load.
See Appendix for additional Back-up time information.
1.5.4 Battery Extension Cable Kit
(6 ft./1.8 m, Part number 86006)
This extended battery cable kit will be used instead of the standard battery cable when Battery Modules (EXBs) are
distant from each other (located in two different enclosures, for instance).
The battery extension cable kit includes a 6 ft. long, straight connector battery power cable and a 6 ft. long battery
detection cable.
Introduction
+++
7 kVA :
11 kVA:
7 min
5 min
20 min
14 min
32 min
22 min
+ +
45 min
30 min
57 min
42 min
72 min
53 min
Standard
EX 5/7/11RT systems
Optional
Configurations
5 kVA :
9 min
25 min 45 min
60 min 84 min 100 min
EX 5/7/11RT EXB 5/7/11RT
EXB 5/7/11RT EXB 5/7/11RT EXB 5/7/11RT EXB 5/7/11RT EXB 5/7/11RT
