1.5.7 Transformer Module - For use with EX 5/7/11RT Power Module
This module provides isolated 120/208/240Vac outputs.
Figure 1-11: Typical Transformer Module contents and connections.
Introduction
EX RT Transformer Module Contents
Tower Stand Expanders
Transformer Module
Quick Start Manual
BATTERY MODULE
EXB RT
POWER MODULE
EX 5/7/11RT
TRANSFORMER
MODULE EX RT
AC NORMAL
INPUT
TRANSFORMER MODULE
OUTPUT TO LOAD
Stabilizer Bracket
(4 screws included)
41
Transformer Rail Kit
Transformer
Cable
