1.5.5 Battery Integration Kit with Casters
(Part number 86005)
Battery Integration Kit is a cart, designed to hold up to 8 modules. It has swivel wheels with brakes, leveling feet,
seismic floor mount panels, plates to lock modules and hardware included. Modules not included.
Figure 1-10: Typical Battery Integration kit with casters setup.
1.5.6 Input/Output Box
Introduction
TRANSFORMER MODULE
(optional)
POWER MODULE
BATTERY MODULES
(up to 6)
(Modules Not Included In Kit)
- I/O Box 5/7kVA Part number 86009
- I/O Box 11kVA Part number 86010
O
F
F
O
