MGE UPS Systems EX-11RT - Contents of EXB 5;7;11 RT Battery Module

Installation and User Manual
Figure 2-2: Contents of EXB 5/7/11RT Battery Module.
Installation 2 — 386-86000-00 B00
Contents of EXB 5/7/11RT Battery Module: (PN 86207 /86209)
Stabilizer Bracket and hardware.
EXB 5/7/11RT.
Tower stand expanders.
Battery Power cable.
Battery/EX RT Transformer/CLA Module rail kit, PN 86002.
Battery detection cable.
EXB Documentation.
Bezel hex drive.
44
43
42
41
40
39
38
29
E
X
B
R
T
39 40 42
41
43
44
(not to scale)
- EXB 5RT Battery Module Part number: 86207.
- EXB 7RT Battery Module Part number: 86207.
- EXB 11RT Battery Module Part number: 86209.
