3.3.1 UPS personalization through external software
Insert the Solution-Pac 2 CD ROM in your CD drive.
◗ At the first Navigator Screen, select "Installation" and follow the instructions to install
Solution-Pac 2 for Windows.
◗ If nothing appears, launch startup.exe
◗ Then go to "Advanced settings" and "UPS settings".
Please note that the Linux/Unix/MacOS versions of Personal Solution-Pac do not include this feature.
3.3.2 Final Startup sequence
Press the <ON> button more than 3 seconds.
◗ After UPS internal test sequence, the green LED goes on.
CAUTION During the startup, if the Bypass AC source is out of
tolerance, there will be a 10msec output interrupt.
15
EX 5/7/11RT Systems
Operation3 — 6 86-86000-00 B00
