2.2 Contents of Standard EX 5/7/11RT Systems
IMPORTANT Packaging must be destroyed according to waste management standards.
Recycling icons are displayed for easy selection.
Figure 2-1: Contents of EX 5/7/11RT Power Module.
Installation
Contents of EX 5/7/11RT Power Module: (PN 86215 / 86216 / 86217)
EX 5/7/11RT Power Module.
Two sets of tower stands.
RS232 communication cable.
Product documentation.
Input/Output Box. (PN 86009 for EX 5/7RT; 86010 for EX 11RT)
Solution-Pac 2 CD.
Power Module Rail Kit, PN 86001.
