MHM SYNCHROPRINT 3000 - External Supply and Connection Ports

Operating Instructions - Synchroprint 3000 (Manual-Registration Version)
________________________________________________________________________________
Operating Instructions - Synchrprint 3000 (Manual-Registration Version) V1-1 Page 15 of 49
4.4. External supply/Connection ports
Connections for compressed air and mains electricity are located on the base unit of the
Synchroprint 3000 as standard. Overhead supply connections may be ordered optionally but only at
time of order, to enable supplies to enter the machine from above, through the centre column.
4.4.1. Electrical Connections
The electrical requirements are as follows:
Description
Requirement/Value
Supply voltage
3x 210/380/440 V
Supply frequency
50/60 Hz ± 5 %
Connection power
2.5 kW + (0.6 kW x “number of print heads”)
(= “power for indexer main drive” + “power per print head” x
“number of print heads”)
4.4.2. Compressed Air Requirements
Type of machine
SP 8
SP 10
SP 12
SP 14
SP 16
SP 18
SP 20
Air consumption (l/min.)
500
550
600
650
700
750
800
Minimum air pressure
8 bar / 116 psi (filtered, dry air only)
Please observe the general safety regulations for electrical connections when
connecting the mains supply to the Synchroprint 3000. Avoid any contact with
live components.
A step/cover plate must be placed securely over any supply lines crossing the
floor.
All flash cure units must be supplied through a separate/independent
connection. Please observe the precise technical data from the flash cure unit
specification sheet.
