Operating Instructions - Synchroprint 3000 (Manual-Registration Version)
________________________________________________________________________________
Operating Instructions - Synchrprint 3000 (Manual-Registration Version) V1-1 Page 29 of 49
7.3. Start-up of the Machine
The following points must be checked prior to start-up of the machine:
Mains voltage and compressed air must be available.
The main power switch must be turned on.
The machine may then be started with the Main control switch. The following screen will be
displayed:
1. The IPC (industrial PC) is booting…
2. Display of the MHM logo and the machine model/type…
3. Command screen ‘START’
Before starting up the machine all points listed in chapter 5.1 “Start-up
Instructions” must be complied with. Failure to do so may result in personal
injury or damage to the machine along with cancellation of the warranty.
The start-up of the machine by the customer is only permitted after the initial
start-up upon completion of commissioning by one of MHM’s service
engineers or a technician of a dealer authorised by MHM.
If detected, the ‘START’ screen
will display the error message
“EMERGENCY STOP or
SAFETY-LINE” and will
change to the command screen
‘TABLE POSITION’.
‘MENU’ leads directly to the
command screen ‘MENU’.
However if the turntable is out
of position it will not be
possible to commence
production.
