Operating Instructions - Synchroprint 3000 (Manual-Registration Version)
________________________________________________________________________________
Operating Instructions - Synchrprint 3000 (Manual-Registration Version) V1-1 Page 21 of 49
6.7.2. Squeegee Arm Motor
The squeegee/print arm motor is used to drive the squeegee carriage back and forth, controlled
precisely by the frequency converter.
6.7.3. Frequency Converter
The frequency converter controls the squeegee drive motor. The motor and frequency converter
have already been adjusted by MHM, and no further adjustment should be necessary.
6.7.4. Squeegee/print arm
The squeegee carriage, squeegee stroke length adjustment, control keypad and control knobs for the
squeegee carriage speed & pressure are all located on the squeegee arm.
6.7.5. Screen Adjustment/Micro-Registration
The screen adjustment/micro-registration is used for the precise positioning of the screens. Each
screen may be positioned forwards/backwards by means of a single handwheel adjuster located at
the front of each individual print station. For left/right adjustment there are two handwheel adjusters
located at the front and rear of each individual print station. Adjustment is free from play and self-
locking, therefore no additional clamping is required.
6.7.6. Squeegee stroke length adjustment
The squeegee stroke length adjustment may be used to adjust the precise travel of the squeegee
carriage. There are individual sensors on each print station to adjust the front and rear positions.
Minimising the travel of the squeegee carriage helps to reduce printing times and increase
production.
6.7.7. Squeegee/print arm lock-down
Pressing the squeegee/print arm lock raises the entire squeegee/print upwards, providing un-
obstructed access to the screens.
