Operating Instructions - Synchroprint 3000 (Manual-Registration Version)
________________________________________________________________________________
Operating Instructions - Synchrprint 3000 (Manual-Registration Version) V1-1 Page 45 of 49
RUNTIME STATION
No.1-18
‘Time out’ limit exceeded for
squeegee motion. (Usually 8 sec
limit). Station No. will be indicated.
Relevant squeegee carriage may be
obstructed. Check squeegee drive
including belt. Note the error message
displayed on the frequency converter.
SQUEEGEE POSITION
STATION No.1-18
The squeegee carriage is not at the
front or rear stroke length sensor.
(Mid-position). Station No. will be
indicated.
Push the squeegee carriage manually to
the correct position.
9. Shutting Down the Synchroprint 3000
9.1. Switching Off the Machine after Normal Operation
The following procedure must be observed when switching off the Synchroprint 3000 after normal
operation:
 Stop the current production.
 Clean all print stations.
 Save all the current settings by pressing the ‘SAVE’ key in the ‘MENU’ screen.
 Lower all the print stations into the correct registration points by pressing the ‘SCREEN
UP/DOWN’ key in the ‘ADJUST’ screen.
 Switch off the Synchroprint 3000 by the main power switch (see 6.1 Overview Machine
Parts).
9.2. Long-term Shutdown
This refers to a scheduled long-term shutdown of the Synchroprint 3000.
The following procedure must be followed:
 Save all the current settings by pressing the ‘SAVE’ key in the ‘MENU’ screen.
 Remove all the printing screens along with the pallets.
 Lower all the print stations into the correct registration points by pressing the ‘SCREEN
UP/DOWN’ key in the ‘ADJUST’ screen.
 Switch off the compressed air supply.
 Switch off the Synchroprint 3000 by the main power switch (see 6.1 Overview Machine
Parts).
 Disconnect the power supply.
 Carry out thorough cleaning of the machine.
 Carry out any necessary maintenance work.
If the compressed air supply is turned off (e.g. overnight), the print stations
will lower or drop uncontrolled. In this case the turntable must not be moved
after the shutdown in order to prevent damage to the main registration
blocks/points of the machine. This would result in the cancellation of the
warranty.
