14 69D0023
CDV Series Gas Fireplace
VENT INSTALLATION
Figure 9 -
Combustible Clearances for Vent Pipe - CDVR Series
A Minimum of 3" Clearance
to the Top Is Required Along
Horizontal Length until Flue
Pipe Penetrates Outside Wall.
WARNING
A Minimum 1"
Clearance to
Combustibles
Permitted All
Around Flue
at Outside
Wall
REAR VENT INSTALLATION
WARNING
WARNING
until the
ue penetrates the outside wall.
at this point of penetration.
on all sides of the pipe.
