6 69D0023
CDV Series Gas Fireplace
PRE-INSTALLATION INFORMATION
ORIFICE SIZES, PRESSURES AND BTUs
NATURAL GAS PROPANE GAS
Manifold Press: (W.C.) 3.5" Manifold Press: (W.C.) 10"
Maximum Supply Pressure 10.5" Maximum Supply Pressure 13"
Minimum Supply Pressure 4.5" Minimum Supply Pressure 11"
BEFORE YOU START
Read this homeowner manual thoroughly and follow all instructions carefully. Inspect all contents for shipping
damage and immediately inform your dealer if any damage is found. Do not install any unit with damaged, incom-
plete, or substitute parts. Check your packing list to verify that all listed parts have been received. You should
have the following:
• Fireplace (Firebox and Burner System) • Rock Wool
• Log Set • Volcanic Rock
ITEMS REQUIRED FOR INSTALLATION
Tools: Building Supplies:
• Phillips Screwdriver • Framing Materials
• Hammer • Wall Finishing Materials
• Saw and/or saber saw • Caulking Material (Noncombustible)
• Level • Fireplace Surround Material (Noncombustible)
• Measuring Tape • Piping Complying with Local Codes
• Electric Drill and Bits • Tee Joint
• Pliers • Pipe Sealant Approved for use with Propane/LPG
• Square (Resistant to Sulfur Compounds)
• Pipe Wrench
The classication “noncombustible material” includes,
but is not limited to stone, brick and mortar. Noncom-
bustibles are safe to overlay the black-painted metal
face (including radiant plates) and do not pose a re
hazard. Do not allow any noncombustible nish material
to extend past or interfere with replace opening.
The classication “combustible material” includes, but
is not limited to plywood, drywall and particle board.
Combustible materials may contact the sides, bottom
or back of rebox. Do not overlay the black painted face
with combustible materials.
Natural Propane Natural Propane Natural Propane Natural Propane
Max. BTU/hr Input 18,000 18,000 18,000 18,000 20,000 20,000 20,000 20,000
Min. BTU/hr Input 10,000-13,000 10,000-13,000 10,000-13,000 10,000-13,000 15,000 15,000 15,000 15,000
Orice size #45 1.28 mm #45 1.25 #44 1.35 mm #44 1.35 mm
Natural Propane Natural Propane Natural Propane Natural Propane
Max. BTU/hr Input 24,000 24,000 24,000 24,000 24,000 24,000 24,000 24,000
Min. BTU/hr Input 17,000 18,000 17,000 18,000 17,000 18,000 17,000 18,000
Orice size 2.35 mm 1.45 mm 2.35 mm 1.45 mm 2.35 mm 1.45 mm 2.35 mm 1.45 mm
HIGH ELEVATIONS
Input ratings are shown in BTU per hour and are certi-
ed without deration for elevations up to 4,500 feet
(1,370 m) above sea level.
For elevations above 4,500 feet (1,370 m) in USA,
installations must be in accordance with the current
ANSI Z223.1/NFPA 54 and/or local codes having
jurisdiction.
In Canada, please consult provincial and/or local
authorities having jurisdiction for installations at eleva-
tions above 4,500 feet (1,370 m).
