69D0023 47
CDV Series Gas Fireplace
FIREBOX COMPONENTS
ILLUSTRATED PARTS LISTS
Standard Features
1. Junction Box Assembly 1 26D2128K 26D2128K 26D2128K 26D2128K 26D2128K 26D2128K 26D2128K 26D2128K
2. Black Louver 6 54D0246 54D0246 26D0695 26D0695 26D0697 26D0697 26D0699 26D0699
3. Glass Frame Assembly 1 69D0238 69D0238 69D0028 69D0028 69D1107 69D1107 69D2105 69D2105
Factory Installed Service Parts
2. Brass Louver 6 54D0249K 54D0249K 26D0701K 26D0701K 26D0703K 26D0703K 26D0705K 26D0705K
4. Thermostat Sensor
Blower 1 26D2870 26D2870 26D2870 26D2870 26D2870 26D2870 26D2870 26D2870
5. Cottage Clay Firebrick
Rear 1 69D0221 26D7069 69D0040 69D0041 69D1023 69D1022 69D2019 69D2020
5. Tavern Brown Firebrick
Rear 1 69D0222 54D0284 69D0044 69D0045 69D1025 69D1024 69D2021 69D2022
6. Cottage Clay Firebrick
Right / Left 2 26D7068 26D7068 69D0042 69D0042 69D0042 69D0042 69D0042 69D0042
6. Tavern Brown Firebrick
Right / Left 2 54D0285 54D0285 69D0046 69D0046 69D0046 69D0046 69D0046 69D0046
7. Blower Motor 1 26D0748 26D0748 26D0748 26D0748 26D0748 26D0748 26D0748 26D0748
2. Brass Louver 1 L30BR L30BR L32BR L32BR L36BR L36BR L42BR L42BR
2. Pewter Louver 1 L30PW L30PW L32PW L32PW L36PW L36PW L42PW L42PW
9. Curved Design
Brass Trim 1 BRTK30C BRTC30C BRTK32C BRTK32C BRTK36C BRTK36C BRTK42C BRTK42C
9. Curved Design
Pewter Trim 1 PWTK30C PWTK30C PWTK32C PWTK32C PWTK36C PWTK36C PWTK36C PWTK36C
10. T-stat Blower w/
Speed Control 1 BLOT BLOT BLOT BLOT BLOT BLOT BLOT BLOT
