34 69D0023
TANTANWHITE
GREEN
BLACK
BLACKBLACK
Receptacle
Junction
Box
120VAC
CDV Series Gas Fireplace
The junction box for the fan/blower systems has been factory installed. This system requires that 110-120 VAC
to be wired to the factory installed junction box before the replace is permanently installed. Figure 46.
Optional Thermostatic Switch
Speed Control
Figure 46 - Blower Wiring Diagram
Figure 47 - Speed Control Location
ELECTRICAL INSTALLATION
Speed Control
