MHSC CDVR33 - Fireplace Framing

69D0023 7
B
A
1
/2" or
5
/8"
C
A
G
C
G
A
1
/2" or
5
/8"
H
G
D
F
E
A
C
CDV Series Gas Fireplace
FIREPLACE FRAMING

Firebox framing can be built before or after the appli-
ance is set in place. Construct rebox framing following
Figure 2 and the chart below for your specic installation
requirements. Refer to Figure 5 on Page 9 for rebox
dimensions. The framing headers may rest on the top
of the rebox standoffs.
top of standoffs.
The rebox may be installed directly on a combustible
oor or raised on a platform of an appropriate height.
When the rebox is installed directly on carpeting, tile,
or other combustible material, other than wood ooring,
the rebox shall be installed on a metal or wood panel
extending the full width and depth of the enclosure.
CDVR Series Corner Installation
CDVR Series Stud Location
CDVR Series Inside Chase Installation
CDVR Series Recessed Installation or
Outside Chase
Figure 2 - Framing Dimensions
WARNING

    

CDVR33 CDVR36 CDVR42 CDVR47
A 33
1
/4" 37
1
/2" 41
1
/4" 47
1
/4"
B 35" 38
1
/8" 38
1
/8" 38
1
/8"
C 21
1
/2" 22
3
/8" 26
1
/8" 32
1
/8"
D 10
3
/4" 11" 12
3
/4" 15
3
/4"
E 48
3
/4" 52
7
/16" 56
7
/16" 62
7
/16"
F 24
1
/2" 26
3
/16" 28
3
/8" 31
5
/16"
G 13
3
/4" 15
1
/4" 15
1
/4" 15
1
/4"
H 34
1
/2" 37
1
/16" 39
11
/16" 43
7
/8"
