8 69D0023
B
A
1
/2" or
5
/8"
C
A
G
C
G
A
1
/2" or
5
/8"
H
G
D
F
E
A
C
CDV Series Gas Fireplace
FIREPLACE FRAMING

Firebox framing can be built before or after the appliance is set in place. Construct rebox framing following
Figure 3 and the chart below for your specic installation requirements. See Figure 4 on Page 10 for rebox
dimensions. The framing headers may rest on the top of the rebox standoffs.
top of standoffs.
The rebox may be installed directly on a combustible oor or raised on a platform of an appropriate height.
When the rebox is installed directly on carpeting, tile, or other combustible material, other than wood ooring,
the rebox shall be installed on a metal or wood panel extending the full width and depth of the enclosure.
CDVT Series Corner Installation
CDVT Series Stud Location
CDVT Series Inside Chase Installation
CDVT Series Recessed Installation or Outside Chase
Figure 3 - Framing Dimensions
WARNING

    

CDVT33 CDVT36 CDVT42 CDVT47
A 33
1
/4" 37
1
/2" 41
1
/4" 47
1
/4"
B 35" 38
1
/8" 38
1
/8" 38
1
/8"
C 21
1
/2" 22
3
/8" 26
1
/8" 32
1
/8"
D 10
3
/4" 11" 12
3
/4" 15
3
/4"
E 48
3
/4" 52
7
/16" 56
7
/16" 62
7
/16"
F 24
1
/2" 26
3
/16" 28
3
/8" 31
5
/16"
G 13
3
/4" 15
1
/4" 15
1
/4" 15
1
/4"
H 34
1
/2" 37
1
/16" 39
11
/16" 43
7
/8"
