Optidew User’s Manual
24 97551 Issue 1, February 2018
OPERATION
Display
Figure 19
Display screen
Resolution
Changes the number of decimal places for all displayed
parameters
Available input: 1 DP, 2 DP
Temperature Unit
Measurement unit for temperature values
Available input: °C, °F
Pressure Unit
Measurement unit for pressure values
Available input: kPa, psig, psia, barg, bara
Timebase
X axis span for trend graph on main screen
Input format: hh:mm
Limits: 00:01 to 10:00
Stability
Determines a stable measurement following DCC, which is
conditional to release Data Hold. Entered value is ΔDP over 30s.
Available input: 0.2 to 20
Display Hold
When enabled, values on display are also held during Data Hold
Available input: Off, On
Language
Sets User Interface language
Available input: English, Deutsch, Español, Français, Italiano,
Português, USA, Russian, Chinese, Japanese
Brightness
Display backlight control
Available input: 0 to 100%
