Optidew User’s Manual
52 97551 Issue 1, February 2018
APPENDIX B
110 006E R|W boolean Pressure Correction Enabled
111 006F R|W uint16 Pressure Correction Direction
0=To atmospheric
1=From atmospheric
Pressure Sensor Configuration
112 0070 R|W uint16 Pressure Sensor Source
0=External
1=Manual
113 0071 R|W uint16 Pressure Sensor Unit
0=psig
1=psia
2=barg
3=bara
4=kPa
114 0072 R|W float Manual Pressure MS
115 0073 R|W Manual Pressure LS
116 0074 R|W float Pressure Range Low Ma MS 4mA
117 0075 R|W Pressure Range Low Ma LS
118 0076 R|W float Pressure Range High Ma MS 20mA
119 0077 R|W Pressure Range High Ma LS
120 0078 R|W float Pressure Range Low MS Pressure Sensor Zero
121 0079 R|W Pressure Range Low LS
122 007A R|W float Pressure Range High MS Pressure Sensor Span
123 007B R|W Pressure Range High LS
Temperature Sensor Configuration
124 007C R|W uint16 Temperature Sensor Source
0=External
1=Manual
125 007D R|W float Manual Temperature MS
126 007E R|W Manual Temperature LS
Instrument Configuration
127 007F R|W uint16 DCC Setpoint Mode
0=External
1=Manual
128 0080 R|W int16 DCC Temperature Setpoint (Degrees * 100)
129 0081 R|W uint16 DCC Interval Mode
0=Auto (Recommended)
1=Manual
130 0082 R|W uint16 DCC Interval Mins
131 0083 R|W uint16 DCC Duration Mins
