Microsoft Surface-2 User Manual

© 2014 Microsoft Page 7
Set up your Surface
Grab your Surface and let’s go!
Before you start… Make sure a wireless network is available and you have the network password (if the network
is secured).
Plug in and turn on
1. If you have a Typing Cover, bring it close to your Surface, so that it clicks into place (see picture).
2. Flip out the built-in kickstand on the back of Surface (either position).
3. Plug the power cord into a wall outlet or power strip.
4. Connect the power connector to the charging port on Surface (either direction works).
The ring of light near the end of the connector means Surface is getting power.
5. Press and release the Power button (on the top right edge).
Surface turns on and setup begins.

Microsoft Surface-2 Specifications

General

Processor cores	4
Processor model	Tegra 4
Processor family	NVIDIA Tegra
Processor frequency	1.7 GHz
Processor manufacturer	NVIDIA
Internal memory	2 GB
Panel type	TFT
Pixel density	208 ppi
Display diagonal	10.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Native aspect ratio	16:9
Built-in microphone	Yes
Number of built-in speakers	2
Microphone in	No
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
AC adapter power	24 W
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Storage media	eMMC
Internal storage capacity	32 GB
Platform	Windows
Bundled software	Microsoft Office 2013 RT
Operating system installed	Windows RT
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	3.5 MP
Battery life (max)	10 h
Battery technology	-
Battery recharge time	4 h
Device type	Mobile tablet
Form factor	Slate
Product color	Gray

Weight and Dimensions

Depth	8.9 mm
Width	275 mm
Height	173 mm
Weight	675 g
