• 22 •
Main Menu (menu icon)
UTILITIES SETUP
(icon) (Continued from DISPLAY)
BACKLIGHT TIME (scrolling)
Press
ENTER.
BACKLIGHT TIME (scrolling)
Select the duration of the backlight when the analyzer is inactive.
The range is 0 to 10 seconds.
LANGUAGE (icon)
Press
ENTER to select a language.
LANGUAGE (check boxes)
7 LANGUAGES: ENGLISH, GERMAN, SPANISH, ITALIAN, FRENCH,
PORTUGUESE AND RUSSIAN
UPDATE (icon)
The UPDATE utility installs
ULTRA software upgrades from an SD memory card.
MAIN MENU (icon)
Displays the Main Menu.
DMM (icon)
Press ENTER to display the digital multimeter menu.
DC VOLTS
(icon)
Press
ENTER.
DC VOLTMETER
The DC voltmeter measures from real-time DC voltage from 0 to 25 Vdc.
AC VOLTS (icon)
Press
ENTER.
AC VOLTMETER
The AC voltmeter measures real-time AC voltage from 0 to 10 Vac.
SCOPE
(icon)
SCOPE
Real-time voltage trace with a range of 0 to 25 Vdc and four options: AUTO
SETUP, RUN/HOLD, TIME DISPLAY, and FFT DISPLAY.
(To CURRENT)
Main Menu
Chapter 2: Description
Celltron ULTRA
