• 47 •
Jar data
The values in JAR DATA (JAR STATISTICS on the printout) are the test results for jar posts and
straps. The analyzer displays and prints results in the order in which jar and straps were tested. The
format is the same for displayed and printed results. If you print results from JAR DATA, the printout
will show the results for the selected jar or strap, not the entire string.
NOTE: You can retest any jar or strap displayed in JAR DATA. Refer to Retesting after testing the
string in Chapter 6.
** NOTE: The analyzer displays and prints dashes (
_ _ _ _ _
) if you selected VOLTS ONLY
in BATTERY SETUP, or if you selected VOLTS THEN CONDUCTANCE, but did not complete
the conductance measurement.
1
6μΩ
PRINT
’C’ END
G: VOLTS: GOOD
2.263VDC
REF:
S1
1000
TEMP: 25 °C
Jar is above low
voltage warning
threshold
Strap resistance
in microhms
Temperature selected
in BATTERY SETUP
Reference
value selected
in BATTERY SETUP
First strap tested
900
PRINT
’C’ END
G: GOOD VOLTS: GOOD
90%
2.263VDC
0.0A AC
0% 60%
REF:
J1
1000
TEMP: 25 °C
Jar is above low voltage
warning threshold
Jar FAIL threshold of
60% of the ref. value
Jar percentage of
ref. value
Temperature selected
in BATTERY SETUP
Estimated AC current
in the battery string
Decision on jar
condition
** Jar mhos/siemens
Ref. value selected in
BATTERY SETUP
First jar tested
Chapter 7: Test results and reportsCelltron ULTRA
