Technical Information
13
CVA 610/CVA 615 Coffee Systems
Warning!
Make sure that power is not supplied to the appliance while installation or
maintenance work is performed.
Disconnect the power supply to the work area by unplugging the appliance,
tripping the circuit breaker or removing the fuse.
The coffee system must be installed into cabinetry before being operated.
1. Plug the appliance into the electrical outlet.
2. Push it all the way back into the cabinet until there is resistance.
3. Open the front of the machine and partially tighten the screws.
4. Carefully turn the lower screws (Figure 2-2, Item 1) to center the machine in the
cabinet.
5. To secure the appliance in the cabinet, tighten the upper screws (Figure 2-2,
Item 2) carefully by hand. Do not use an electric screwdriver.
Figure 2-2: Installation Information
Note:
For further information, refer to the installation manual section of the operating
manual or the Miele installation manual.
