Miele cva 610 Technical Information

Technical Information
75
CVA 610/CVA 615 Coffee Systems
5.47 Brew Unit Present Switch Removal
1. Remove the lid; see Section 5.1.
2. Remove the rear panel; see Section 5.6.
3. Disconnect the switch (Figure 5-52, Item 2).
4. Press the retainers outward to remove the switch.
Figure 5-52: Brew Unit Present Switch Removal
5.48 Dispensing Solenoid Removal
1. Remove the lid; see Section 5.1.
2. Remove the rear panel; see Section 5.6.
3. Remove the beans container; see Section 5.42.
4. Remove the beans container guide; see Section 5.43.
5. Press the solenoid retainers outwards. Slide the solenoid upwards out of its guide.
6. Disconnect the solenoid connections.
5.49 Dispenser Switch Removal
1. Remove the lid; see Section 5.1.
2. Remove the rear panel; see Section 5.6.
3. Remove the beans container; see Section 5.42.
4. Remove the beans container guide; see Section 5.43.
5. Remove the dispensing solenoid; see Section 5.48.
6. Press the switch retainers outwards. Remove the switch.
7. Disconnect the electrical connections.
