Miele PWM 908 User Manual

Operating the washing machine
18
OK
Time

12 00
11 59
10 58
13 01
14 02
Briefly touching a number between the
two lines will bring up the numerical
keypad.
OK
12:00
3
4
21
Time

5 6
7

8
0
9
Once a valid number has been entered,
the OK sensor control will be high-
lighted green.
Pull-down menu
The pull-down menu can be used to
display information, e.g. about a wash
programme.
 11:02

Coloured
items
Status
Time left
h2:27

Main wash
Add laundry


If an orange bar appears at the top of
the screen in the middle of the display,
you can open the pull-down menu.
Touch the bar and drag down with your
finger.
Exiting a menu
 Touch the sensor control to return
to the previous screen.
Entries made before this which have not
been confirmed withOK will not be
saved.
Help display
With some menus Help appears along
the bottom line of the display.
 Touch theHelp sensor control to dis-
play the text.
 Touch the Closesensor control to re-
turn to the previous screen.

Miele PWM 908 Specifications

General

Door hinge	Right
Water fill	Cold, Hot
Drum volume	73 L
Control type	Touch
Loading type	Front-load
Certification	CE, VDE-EMV, VDE, WEEE, IPX4
Product color	Silver
Built-in display	Yes
Custom panel-ready	-
Door opening angle	167 °
Appliance placement	Freestanding
Package depth	768 mm
Package width	660 mm
Package height	940 mm
Package weight	107000 g
Current	10 A
Connected load	5500 W
AC input voltage	400 V
AC input frequency	50 Hz
Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Drum capacity	8 kg
Delay start (max)	96 h
Spin-drying class	A
Maximum spin speed	- RPM
Noise level (spin)	70 dB
Noise level (wash)	46 dB

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	103000 g
