Miele PWM 908 User Manual

Problem solving guide
66
Opening the door in the event
of a blocked drain outlet and/
or power cut
 Risk of electric shock.
Only ever perform cleaning and
maintenance work when the appli-
ance is disconnected from the
power.
Disconnect the washing machine
from the mains electricity supply.
 Open the access panel to the drain
system.
Blocked drain outlet
If the drain outlet is blocked, there may
be a large quantity of water (max. 30l)
left behind in the washing machine.
 Risk of scalding due to hot suds.
Escaping suds will be hot if laundry
has been washed at high temperat-
ures.
Carefully allow all suds to drain off.
Emptying the drum
....For machines with a drain pump
 Place a suitable container under the
access flap.
Remove the drain filter, though not
completely.
 Slowly unscrew the drain filter to let
the water out.
 Tighten the drain filter back up again
if you need to interrupt the flow of
water.

Miele PWM 908 Specifications

General

Door hinge	Right
Water fill	Cold, Hot
Drum volume	73 L
Control type	Touch
Loading type	Front-load
Certification	CE, VDE-EMV, VDE, WEEE, IPX4
Product color	Silver
Built-in display	Yes
Custom panel-ready	-
Door opening angle	167 °
Appliance placement	Freestanding
Package depth	768 mm
Package width	660 mm
Package height	940 mm
Package weight	107000 g
Current	10 A
Connected load	5500 W
AC input voltage	400 V
AC input frequency	50 Hz
Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Drum capacity	8 kg
Delay start (max)	96 h
Spin-drying class	A
Maximum spin speed	- RPM
Noise level (spin)	70 dB
Noise level (wash)	46 dB

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	103000 g
