OM-272384 Page 28
Figure 8-1. Complete Assembly
Item No. Dia. Mkgs. Part No. Description Quantity
1 PB1 186416 Trigger Switch 1
2 288570 Plastic Handle 1
209177 Hardware Kit, Spoolmate Case 1
3 196966 Spool Cover Assy (Including) 1
4 194622 —Spool Defence Shell 1
5 194623 —Spool Shaft 1
6 132529 —Pad, Brake 1
7 194625 —Location Bushing 1
8 194626 —Adjusting Nut 1
9 194627 —Locking Screw 1
10 187239 Cover, Drive Roll 1
11 186414 Push Roll .030/.035 (0.8/0.9 Mm) 1
12 187238 Bearing 1
13 186415 Press Arm W/Shaft, C-Clip Washer 1
14 193999 Spring, Cprsn .310 Od X .040 Wire X 1.380 1
15 Bolt
16 194631 Nut, Brass 1
17 273018 Gearbox Assembly 1
18 186410 Inlet Guide 1
19 186488 Key, Drive Roll 2 Mm X 7 Mm 1
20 186413 Drive Roll .030/.035 (0.8/0.9 Mm) 1
21 B2 273017 Motor 1
22 199385 Gun Tube Assembly (Including) 1
23 050622 —Nozzle, 5 /8 Orf x 1-5/8 Lg 1
24 199387 —Contact Tip .030 (.8MM) 1
♦199388 —Contact Tip .035 (.9MM) 1
25 199390 —Gas Diffuser 1
26 199391 —Gas Nipple 1
27 199393 —Barrel 1
28 196847 —Lock Nut 1
29 206363 —Liner Kit 1
30 199394 —Head Tube Assy 1
31 196398 Buss Bar, Interconnecting (Prior to Serial No, UP120001) 1
31 288571 Kit, Buss Bar Spoolgun (Eff. With Serial No. UP120001) 1
32 111400 Hose, Sae .187 Id X .410 Od X 8.000 1
33 231107 Strain Relief, Cable 1
34 226615 Nut, Handle Plastic 1
35 231108 Spring, Cable 1
36 273019 Cable Assembly, 20 Ft W/Connector Plug 1
37 273020 Spring, Cable Rear 1
38 273021 Handle, Rear 1
39 079974 O-Ring, .500 Id X .103 Cs Rbr 2
40 234236 Connector, Plug 1
41 079878 Connector W/Sockets 1
42 196848 Contact Adapter 1
F
Hardware is common and not available unless listed.
♦Optional
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested Replacement Parts. Model and
serial number required when ordering parts from your local distributor.
