OM-245 849 Page 38
Figure 12-4. Base Assembly
. Hardware is common and
not available unless listed.
1
2
3
Figure 12-4. Base Assembly
(Figure 12-1 Item 5)
Quanti
ty
Description
Part
No.
Dia.
Mkgs.
Item
No.
1 156006060 Base, 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 V56110090 Mount, Nprn 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 956142662 Rating Plate 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
