How to adjust:
Follow the adjusting procedure given below.
Sample pattern
How to adjust If the cut pattern rotates clockwise If the cut pattern rotates counter
as compared with the plotted clockwise as compared with the
pattern, decrease the
θθ
θθ
θ value for the plotted pattern, increase the
θθ
θθ
θ value
roller. for the roller.
Adjustment of the offset
Offset amount of the marked pattern as from the plotted pattern is adjusted in terms of the X- and
Y-axes.
One pattern is used for adjustment.
The illustration below indicates the size of the pattern and the cutting order.
: Point from which marking starts
: Direction of marking
: Pen
30 mm
30 mm
To Next Page
