MIMAKI UJF-3042 MkII Series

To Next Page

To Previous Page

xiv

Position of the warning label

Order No. Label Order No. Label

(1)M903330 (6)M913425

(2)M913563

(UJF-6042MkII/

UJF-6042MkIe)

(7)M913706

(3)M913565

(UJF-3042MkII/

UJF-3042MkII EX/

UJF-3042MkII e/

UJF-3042MkII EX e)

(8)M903239

(4)M907935 (9)M913610

(5)M913423

(10)M913419 (11)M915076
