Chapter 1 Before Use
1-11
1
2
2
2
2
Instructions for using the table
When using jigs, set the width to A3 for UJF-3042MkII/
UJF-3042MkII EX/UJF-3042MkII e/UJF-3042MkII EX e,
A2 (or 674mm) for UJF-6042MkII/UJF-6042MkII e and the
depth to 464mm or less.
If you exceed the dimensions above, the table cannot be
moved.
Connecting the cables
Connecting the USB2.0 interface
cable
Connect a computer to this machine with the USB2.0
interface cable.
Notes on USB 2.0 Interface
When two or more this machines are connected to
one personal computer
When two or more this c are connected to one
personal computer, the personal computer may not
recognize all this machines normally.
Reconnect the unrecognized this machine to another
USB port, if available, and check to see if it is
recognized.If the this machine is not recognized by the
newly connected USB port, use USB 2.0 repeater
cables available on the market.
Notes on peripheral devices in USB high speed mode
When a peripheral device (USB memory or USB HDD) to
be operated in USB high speed mode is connected to the
same personal computer that a this machine is
connected to, the USB device may not be recognized.
When this machine is connected to the personal
computer to which an external HDD is connected via
USB, the speed of data output to this machine may
drop.That can cause the head unit to stop temporarily
at the right or left end during printing.
464mm
364mm
464mm
• UJF-3042MkII/3042MkII EX/3042MkII e/3042MkII EX e
• UJF-6042MkII/6042MkII e
674mm
• Prepare the USB2.0 interface cable. (USB2.0
interface cable is not supplied with this machine.)
• Your RIP is required to support USB2.0 interface.
• If USB2.0 interface is not installed in your
computer, ask a RIP maker near you or our branch
office.
• Your RIP must be compatible with USB 2.0.
To Next Page
