3-2
3.2.3 Electrical Requirements
Check that the system cables, power cords, and power plugs are not damaged, and that the
pins are not loose. In case of any damage, remove it from use.
WARNING
Use only properly grounded power outlets.
Use the supplied power cord only!
Voltage 100 to 240V AC
Current 0.9 to 0.5A
Frequency 50/60 Hz
3.3 Equipment Installation
Follow the procedure below to install the equipment:
1. Ensure the main unit and all accessories are not damaged.
2. Install the battery (optional). For detailed operations, please refer to the operator’s
manual of the vital signs monitor.
3. Connect AC power.
4. Connect the accessories.
The vital signs monitor can be mounted on a wall bracket or on a trolley support. The wall
bracket or trolley support can be ordered as an optional accessory. Each type of mounting
bracket is delivered with a complete set of mounting hardware and instructions. For
detailed installation information, please refer to Wall-mount Bracket Instructions for Use
(PN: 0010-20-42933) and Rollstand Instructions for Use (PN: 0010-20-42934).
CAUTION
Use only Mindray supplied or approved mounting solutions.
The mounting bracket should be installed by qualified service personnel.
3.4 Preparation for Power on
1. Before you start using the equipment, check for any mechanical damage and
make sure that all external cables, plug-ins and accessories are properly
connected.
2. Plug the power cord into the AC power source. If you run the equipment on
battery power, ensure that the battery is sufficiently charged.
3. Press the
button on the front panel to turn on the equipment.
