Mindray Accutorr 3 Service Manual

6-2
6.3 Disassembling the Main Unit
NOTE
 To disassemble the equipment, place the equipment on a work surface free
from foreign material, avoiding damaging the screen.
 All the operations should be performed by qualified service personnel only.
 Operations relating to optional parts may not apply to your equipment.
6.3.1 Disassembling the Temperature Module (Optional)
Lay the monitor on a table as shown below. Unscrew the two M3×6 screws, pull
the Temperature module up, and disconnect the Temperature cable.
6.3.2 Separating the Front and Rear Half of the Monitor
1. Lay the monitor on a table as shown below. Unscrew the four M3 screws.
