Mindray Accutorr 3 - 8 Hardware and Software Upgrade; Hardware Upgrade

8-1
8 Hardware and Software Upgrade
8.1 Hardware Upgrade
The vital signs monitor supports upgrade of NIBP, SpO
2
and Temperature functions.
8.1.1 Upgrade Package
Upgrade package Description of upgrade package PN of upgrade package
SpO
2
Masimo SpO
2
upgrade kit 115-023200-00
Nellcor SpO
2
upgrade kit 115-018267-00
Temp Temperature module 115-017687-00
Note: measurement accessories are not included in the above upgrade packages.
8.1.2 Upgrading Parameter Modules
8.1.2.1 Upgrading Nellcor SpO
2
List of upgrade package:
 A Nellcor SpO
2
board; and,
 A connector panel assembly of the same SpO
2
board.
1. Disassemble the power management board and parameter connector panel
assembly as described in section 6.3 Disassembling the Main Unit.
2. Remove the SpO
2
board from the disassembled power management board
assembly as described in section 6.3.5Removing the Parameter Board (SpO2
Optional) and Power Management Board, and assemble the SpO
2
board in the
upgrade kit.
3. Install the power management board assembly with the SpO
2
board and the
connector panel assembly in the service kit into the main unit as described in
section 6.3 Disassembling the Main Unit.
8.1.2.2 Upgrading Masimo SpO
2
List of upgrade package:
 A Power Management Board Assembly; and,
 A parameter connector panel assembly.
1. Remove the power management board assembly and connector panel assembly
as described in section 6.3 Disassembling the Main Unit.
