Mindray Accutorr 3 Service Manual

6-6
6.3.6 Disassembling Pumps and Valves
1. Cut the two cable ties and remove the NIBP pump.
2. Unscrew the two M3×6 screws as indicated and remove the valve.
6.3.7 Disassembling AC/DC Power Board and Battery Converter Board
1. Unscrew the four M3×6 screws as indicated and remove the AC/DC power board.
Cable tie
