Mindray Accutorr 3 Service Manual

8-2
2. Install the power management board assembly and the connector panel
assembly in the service kit into the main unit as described in section 6.3
Disassembling the Main Unit.
8.1.3 Upgrading Temp
List of upgrade package:
 A Temperature module with cables; and,
 Two M3×6 screws.
Remove the decorative cover from the Temperature module connector. Install the
Temperature module onto the main unit as described in section 6.5 Disassembling the
Temperature Module (Optional).
8.1.4 Enabling Parameter Functions
1. Turn on the monitor. Within 10 seconds after you hear a beep, press and hold the
and the buttons simultaneously, and the system starts to identify
the currently configured modules.
The labels of parameters start to flash till the end of module identification. Then
the results are displayed in corresponding parameter areas,
 NIBP and Temperature parameter areas: means "this module is
configured on this equipment" while
means the contrary.
 SpO
2
parameter area: Number”2” means Masimo SpO
2
module, “3” means
Nellcor SpO
2
module.
 PR parameter area: means "SpO
2
module is configured on this
equipment" while
means the contrary.
2. Restart the monitor.
8.2 Software Upgrade
Software upgrades must be performed by Mindray, NA authorized service personnel. Call
Service Dispatch 1 800 288-2121 ext: 7875.
