7-1
7 Disassembly and Repair
7.1 Tools Required
To disassemble and replace the parts and components, the following tools may be required:
Philips screwdrivers
Tweezers
Needle nose pliers
Clamp
7.2 Preparations for Disassembly
Before disassembling the equipment, finish the following preparations:
Stop patient monitoring, turn off the equipment, and disconnect all the accessories and peripheral devices.
Disconnect the AC power source and remove the battery.
WARNING
Before disassembling the equipment, be sure to eliminate the static charges first. When disassembling the
parts labeled with static-sensitive symbols, make sure you are wearing electrostatic discharge protection
such as antistatic wristband or gloves to avoid damaging the equipment.
Properly connect and route the cables and wires when reassembling the equipment to avoid short circuit.
Select appropriate screws to assemble the equipment. If unfit screws are tightened by force, the equipment
may be damaged and the screws or part may fall off during use, causing unpredictable equipment damage
or human injury.
Follow correct sequence to disassembly the equipment. Otherwise, the equipment may be damaged
permanently.
Be sure to disconnect all the cables before disassembling any parts. Be sure not to damage any cables or
connectors.
Be sure to place removed screws and disassembled parts properly, preventing them from being lost or
contaminated.
Place the screws and parts from the same module together to facilitate reassembling.
To reassemble the equipment, first assemble the assemblies, and then the main unit. Carefully route the
cables.
Make sure that the waterproof material is properly applied during reassembling.
