8.3.10.2 Parts List
SN Description FRU part number
1 AG watertrap receptacle 9200-10-10560
2 Gas outlet /
3 Front housing of B1 module 801-9261-00032-00
5 Silicone tube
7 Module indicator and cable
4 Nut, Stainless Steel M5 GB6170 /
6 IBP signal cable (3-way) 009-001972-00
8 Cable between the AG module and converter board 009-001976-00
9 Cable between the converter board and M03B module 009-001971-00
10 C.O./IBP (M03B) module M03B-30-26064
11 IBP insulator for B module /
12 External module interface board (RS232) 801-9261-00024-00
13 Screw, pan head Phillips, M3×6 /
14 Screw, pan head, Phillips, M3×8 /
15 A module button 043-001891-01
16 Spring washer /
17 Screw, Pan head with washer, Phillips M3×6 /
18 Screw, self-tapping, PT3×10 /
19 Module label (no manufacturer information) /
20 External converter board (B modules) /
21 Lock for B module 043-001899-01
22 Rear housing of B modules /
23 Cable between the converter board and copper board 009-001970-00
24 Bracket for B1 module /
25 B module pipe shield /
26
IBP_CO_AG main unit（with 0
2
)(FDA)
115-030772-00
27 C.O. signal cable 009-001973-00
