Mindray DC-8 EXP Service Manual

Function and Performance Checking Method 5-7
 Parameters that can be adjusted to optimize the Color Mode image are indicated in the
following.
Control
Panel
Gain, Depth, iTouch, Steer, Scale
Touch
Screen
Invert, Baseline, B/C Wide, Dual Live, Image quality, Flow State, Priority, Packet Size,
Map, Wall Filter, Line Density, Smooth, Persistence, Velocity Tag
4. Power mode
 In Power mode scanning, the image parameter area in the upper left corner of the screen
displays the real-time parameter values as follows:
Display
F
G
WF
PRF
Parameter
Frequency
Power
Gain
Power Wall
Filter
Pulse
Repetition
Frequency
5. PW/CW mode
 The parameters will be displayed in the image parameter area on the left part of the screen as
follows:
Display
F
G
PRF
WF
SVD
SV
Angle
Parameters
Frequency
Gain
Pulse
Repetition
Frequency
WF
(Wall
Filter)
SV
Position
SV Size
(only CW )
Angle
 Parameters that can be adjusted to optimize the PW/CW Mode image are indicated in the
following.
Control Panel
Gain, iTouch, Baseline, PW Steer, Scale, Angle
Menu
Display Format, Invert, Duplex/ Triplex, Quick Angle, Wall Filter, Image Quality,
Tint Map, Dynamic Range, Trace Area, Speed, SV,
Gray Map, T/F Res, Auto Calc, Auto Calc Para, HPRF, Auto Calc cycle,
Touch Panel
Volume, A. power
5.4.2.2 Basic Measurements
Procedure
Standard
In B image mode:
Press <Measure>:
Press <Caliper> key
The system enters application measurements
The system enters general measurement mode.
Perform any 1-2 measurements (e.g., length, area), the
results will display at the lower part of the image.
Press the same key again or press
<Esc>.
Exits measurement.
