Measure Preset 2-17
Setting Default Item
You can set a measurement, calculation or study in the [Selected Items] as the default item. The
default item will be activated automatically while entering the measurement menu containing it.
1. Select an item from the [Menu] list.
2. Click [Default], and the defaulted item is marked with a √ .
To deselect the default tool, select it and click [Default] or set another item as default.
Tips: If a certain study is set to the default item, it displays the submenu of the study
automatically when entering this measurement menu.
Adjusting Item Position
You can adjust the position of the measurement, calculation or study in the [Selected Items] list.
1. Select an item in the [Selected Items].
2. Click [Up]/ [Down].
The order in the list is also the item position in the menu.
2.4.2.4 User-defined Measurement/Calculation/Study
NOTE: Please guarantee the correctness and validity of the formula defined, otherwise Mindray
will not be liable for damage caused by improper definition of the formula.
User-defined Measurement
1. Enter [Measure Preset] -> [Measure] page.
2. Click [New].
The “Measurement Custom Wizard” dialog box pops up, as shown in the following figure.
3. Input Name in the "Measurement Custom Wizard" dialog box, and click [Next].
4. Select the [Tool Type], [App Region] and the Measure Result.
To Next Page
